1022H - 10 SERIES, 22HP W/ 100 LOADER
3.99% for 84 Month Financing to approved credit! $0 Down, $221.99 PER MONTH DELIVERED TO YOUR DOOR!
Get pre-approved with a soft credit pull application through Sheffield Financial.
Tractor & Loader - $221.99 Per month $0 Down, Delivered
Tractor, Loader & Backhoe - $303.15 Per month $0 Down, Delivered
Tractor, Loader & Mower Deck - $258.06 Per month $0 Down, Delivered
Tractor, Loader, Backhoe & Mower Deck - $339.23 $0 Down, Delivered
OUR SMALLEST TRACTOR STILL PACKS A BIG PUNCH
The smallest entry in our subcompact tractor lineup is perfect for the small property owner. The 1022H Sub-Compact Bad Boy Tractor boasts 22 horsepower and over 600 pounds of lift capacity to allow you to stop breaking your back. Featuring four wheel drive with high and low range plus a locking differential and cruise control, this tiny powerhouse is built to handle almost anything you can throw at it. Our automatic hydro-static transmission allows even the novice tractor user to feel comfortable behind the controls and get right to work. With a standard skid steer style front end and Category 1 three-point hitch its quick and easy to attach a variety of implements including our front loader and backhoe.
1022 POWER TRAIN
- Engine: 3 Cylinder, Water-Cooled, Diesel
- Engine HP @ RPM (kw): 21.5 (16)
- Displacement (in) (kw): 60.6 (993)
- Number Of Cylinders: 3
- Fuel Tank (gal)(l): 6.6 (25)
1022 DRIVE TRAIN
- Transmission: HST
- Number Of Speeds: 2 Range
- Clutch: No
- Brakes: Wet, Multi-Disc
1022 PTO
- Type: Independent
- Rear(Mid) PTO Speed: 540 (2,000)
- PTO HP (kw): 15.4 (11.3)
1022 HYDRAULICS
- Type: Power Assisted Hydro-Static
- Total Hydraulic Flow (Power Steering+Implement): 6.3 (2.1+4.2) / 23.8 (8+15.8)
- 3-Point Hitch: Cat 1
- Rear Remote Valve: Optional (Up To 1)
- 3-Point Hitch Lift Capacity @ 24" Behind Lift Point: 679 (308)
1022 ELECTRICAL
- Battery: 12 V, 500 CCA
- Alternator: 12 V, 40 A
1022 DIMENSIONS
- Overall Length Inches (mm): 94.2 (2,394)
- Overall Width Inches(mm): 44.5 (1,130)
- Overall Height Inches(mm): 86.6 (2,200)
- Wheelbase Inches(mm): 53.1 (1,350)
- Minimum Ground Clearance Inches(mm): 8.3 (210)
- Turning Radius: 45˚
- Weight lbs(kg): 1,433 (650)
1022 WHEELS & TIRES
- IND (Front): 18X8.50-10
- IND (Rear): 26X12.00-12
1022 LOADER - MODEL BBL100
- Standard Bucket Size (in): 50"
- Maximum Lift Height (in): 71.3”
- Dig Depth (in): 4.0”
- Lift Capacity To Full Height At Pivot Pin (lbs): 617
- Breakout Force (lbs): 1,253
- Shipping Weight (lbs): 438
1022 BACKHOE - MODEL BBH100
- Standard Bucket Size (in): 12"
- Type: Sub-frame Mounted, Quick Attach
- Maximum Dig Depth (in): 66"
- Dig Force Bucket (lbs): 1,975
- Shipping Weight (lbs): 747
